Oke thanks admin. Thia antenna good.
-
No i mean not that. Above is bad antenna. Very high vswr
-
It's from center antenna or side antenna?
-
How about to put two antenna? Should i space it at 32mm?
-
H Hello, can any one can convert this antenna to 5.700ghz and simulate it? I want to test this antenna as Access point.
-
This too big. Best place in stadium
-
If one line charged can give 9 dBi i think every additional one charged can give 3dBi power. If we put five or seven charged maybe can make upto 45 dBi
-
Ok admin. I will make detail. Wait..
-
Total oouter diameter of circle: 61.999 mm Wire lenght : 747.687 mm
-
Design of Coil antenna Coil inner diameter: 6 mm Number of turns: 7 turn Wire Diameter: 1 mm Spacing between turns: 3 mm Admin can you simulate this design in CST? I think this design is match to the wave vibration.
-
I still thinking how 2.4 gain very short. Not like cell signal can reach few km to user. If with 100mW - 1 watt power and massif mimo design on 30dbi can 2.4 reach to user on 1 km?
-
Yes. I want to modified this design to 2.4 combined between heix and sector. My mission is to improve gain 2.4 wifi hotspot.
-
Raul changed their profile photo
-
I think this design very professional and best design.
-
I also like this one from mimosa.
-
I mean this design for ground and plus connection and also ballun and reflector I still not understand to build it. I want to build this one.
