2.4 & 5.8 GHz WIFI antenna can be devided?

Started by AmateurRadist, October 23

26 posts in this topic

Posted November 11

On 27.10.2024 at 5:34 PM, clanon said:

Think of each Patch as Resistances , since you have 4 patches for 5.8 and two patches for 2.4...(and YOU NEED to end up on 50 ohms) cutting in a half doesn't work for ALL patches...Filters add complexity (BUT adapt impedances to EACH BAND)

thanks, finally after some attempts it worked perfectly vswr <1.5, forgot to take photos
